AMD Ryzen 5 8500G
| General Specifications | |
| Name | : AMD Ryzen™ 5 8500G |
| Family | : Ryzen |
| Series | : Ryzen 8000 Series |
| Form Factor | : Desktops |
| AMD PRO Technologies | : No |
| Regional Availability | : Global |
| Former Codename | : Phoenix |
| Processor Architecture | : 2x Zen 4 , 4x Zen 4c |
| # of CPU Cores | : 6 |
| Multithreading (SMT) | : Yes |
| # of Threads | : 12 |
| Max. Boost Clock | : Up to 5 GHz |
| Max Zen4c Clock | : Up to 3.7 GHz |
| Base Clock | : 3.5 GHz |
| Zen4 Base Clock | : 4.1 GHz |
| Zen4c Base Clock | : 3.3 GHz |
| L2 Cache | : 6 MB |
| L3 Cache | : 16 MB |
| Default TDP | : 65W |
| AMD Configurable TDP (cTDP) | : 45-65W |
| Processor Technology for CPU Cores | : TSMC 4nm FinFET |
| CPU Compute Die (CCD) Size | : 137mm² |
| Package Die Count | : 1 |
| AMD EXPO™ Memory Overclocking Technology | : Yes |
| Precision Boost Overdrive | : Yes |
| Curve Optimizer Voltage Offsets | : Yes |
| AMD Ryzen™ Master Support | : Yes |
| CPU Socket | : AM5 |
| Supporting Chipsets | : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 |
| CPU Boost Technology | : Precision Boost 2 |
| Instruction Set | : x86-64 |
| Supported Extensions | : AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| Max. Operating Temperature (Tjmax) | : 95°C |
| Launch Date | : Q1 2024 |
| *OS Support | : Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Connectivity | |
| Native USB 4 (40Gbps) | : 2 |
| Native USB 3.2 Gen 2 (10Gbps) | : 2 |
| Native USB 2.0 (480Mbps) | : 1 |
| PCI Express® Version | : PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) | : 14 , 10 |
| NVMe Support | : Boot , RAID0 , RAID1 |
| System Memory Type | : DDR5 |
| Memory Channels | : 2 |
| Max. Memory | : 256 GB |
| System Memory Subtype | : UDIMM |
| Max Memory Speed | : 2x1RDDR5-5200, 2x2RDDR5-5200, 4x1RDDR5-3600, 4x2RDDR5-3600 |
| ECC Support | : Yes (Requires platform support) |
| Graphics Capabilities | |
| Graphics Model | : AMD Radeon™ 740M |
| Graphics Core Count | : 4 |
| Graphics Frequency | : 2800 MHz |
| DirectX® Version | : 12 |
| DisplayPort™ Version | : 2.1 |
| DisplayPort Extensions | : Adaptive-Sync , HDR Metadata , UHBR10 |
| DisplayPort Max Refresh Rates (SDR) | : 7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz |
| DisplayPort Max Refresh Rates (HDR) | : 7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz |
| HDMI® Version | : 2.1 |
| HDCP Version Supported | : 2.3 |
| USB Type-C® DisplayPort™ Alternate Mode | : Yes |
| Multi-Monitor Support | : Yes |
| Max Displays | : 4 |
| AMD FreeSync™ | : Yes |
| Wireless Display | : Miracast |
| Max Video Encode Bandwidth (SDR) | : 1080p630 H.264, 1440p373 H.264, 2160p175 H.264, 1080p630 H.265, 1440p373 H.265, 2160p175 H.265, 4320p43 H.265, 1080p864 AV1, 1440p513 AV1, 2160p240 AV1, 4320p60 AV1 |
| Max Video Decode Bandwidth | : 1080p60 MPEG2, 1080p60 VC1, 1080p786 VP9, 2160p196 VP9, 4320p49 VP9, 1080p1200 H.264, 2160p300 H.264, 4320p75 H.264, 1080p786 H.265, 2160p196 H.265, 4320p49 H.265, 1080p960 AV1, 2160p240 AV1, 4320p60 AV1 |
| AMD SmartAccess Memory | : Available |
| AI Engine Capabilities | |
| AMD Ryzen™ AI | : Not Available |
| Product IDs | |
| Product ID Boxed | : 100-100000931BOX |
| Product ID Tray | : 100-000001491 , 100-000000931 |
| Product ID MPK | : 100-100000931MPK |
| Security | |
| AMD Enhanced Virus Protection (NX bit) | : Yes |
