AMD Ryzen 5 7500F Tray
| General Specifications | |
| Name | : AMD Ryzen™ 5 7500F |
| Family | : Ryzen |
| Series | : Ryzen 7000 Series |
| Form Factor | : Desktops, Boxed Processor |
| Market Segment | : Enthusiast Desktop |
| AMD PRO Technologies | : No |
| Regional Availability | : Global |
| Former Codename | : Raphael AM5 |
| Processor Architecture | : Zen 4 |
| # of CPU Cores | : 6 |
| Multithreading (SMT) | : Yes |
| # of Threads | : 12 |
| Max. Boost Clock | : Up to 5 GHz |
| Base Clock | : 3.7 GHz |
| L1 Cache | : 384 KB |
| L2 Cache | : 6 MB |
| L3 Cache | : 32 MB |
| Default TDP | : 65W |
| Processor Technology for CPU Cores | : TSMC 5nm FinFET |
| Processor Technology for I/O Die | : TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | : 71mm² |
| I/O Die (IOD) Size | : 122mm² |
| Package Die Count | : 2 |
| Unlocked for Overclocking | : Yes |
| AMD EXPO™ Memory Overclocking Technology | : Yes |
| Precision Boost Overdrive | : Yes |
| Curve Optimizer Voltage Offsets | : Yes |
| AMD Ryzen™ Master Support | : Yes |
| CPU Socket | : AM5 |
| Supporting Chipsets | : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 |
| CPU Boost Technology | : Precision Boost 2 |
| Instruction Set | : x86-64 |
| Supported Extensions | : AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| Thermal Solution (PIB) | : AMD Wraith Stealth |
| Thermal Solution (MPK) | : AMD Wraith Stealth |
| Max. Operating Temperature (Tjmax) | : 95°C |
| Launch Date | : 07/22/2023 |
| *OS Support | : Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Connectivity | |
| Native USB 3.2 Gen 2 (10Gbps) | : 4 |
| Native USB 3.2 Gen 1 (5Gbps) | : 0 |
| Native USB 2.0 (480Mbps) | : 1 |
| Native SATA Ports | : 0 |
| PCI Express® Version | : PCIe® 5.0 |
| Native PCIe® Lanes (Total/Usable) | : 28 , 24 |
| Additional Usable PCIe Lanes from Motherboard | : X670E 12x Gen4, X670 12x Gen4, B650E 8x Gen4, B650 8x Gen4, A620 4x Gen3 |
| NVMe Support | : Boot , RAID0 , RAID1 , RAID10 |
| System Memory Type | : DDR5 |
| Memory Channels | : 2 |
| Max. Memory | : 128 GB |
| System Memory Subtype | : UDIMM |
| Max Memory Speed | : 2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600 |
| ECC Support | : Yes (Requires mobo support) |
| Graphics Capabilities | |
| Graphics Model | : Discrete Graphics Card Required |
| Product IDs | |
| Product ID Tray | : 100-000000597 |
| Product ID MPK | : 100-100000597MPK |
| Key Features | |
| Supported Technologies | : AMD EXPO™ Technology , AMD Ryzen™ Technologies |
